Flat Bed Die Cutter
Yoco Jy 105 E/T Automatic Flat Bed Die Cutter And Foil Stamping, Year 2007
U48231125
Connected
EUROPE ·
2007
The price only available for registered users
Description
We present YOCO JY 105 E/T AUTOMATIC FLAT BED DIE CUTTER AND FOIL STAMPING, max. format 750mm x 1060mm / 29.5" x 41.7", manufactured in 2007.
The machine is in VERY GOOD CONDITION, connected, can be inspected at any time and is available immediately.
Machinery Details:
- Maximum mechanical Speed:
- Die cutting speed: 7500 sheet/hour
- Stamping speed: 6000 sheet/hour
- Maximum Sheet Size 750 × 1050mm / 29.5" x 41.33"
- Minimum Sheet Size 380 × 450mm / 15" x 17.7"
- Maximum Cutting Size: 720 × 1040mm / 28.3" x 41"
- Maximum Foil Stamping Size: 730 × 1040mm / 28.7" x 41"
- Minimum Grip Margin 8mm / 0.31"
- Maximum Pressure: 300 Tons
- Max. Sheet Thickness: From 80g/m2 to B Corrugated Board
- Machine Weight aprox.:18.5 Tons
- Non-stop Feeder
- Die Cutting Section
- Stripping Section
- Delivery Section
- Heating Zones: 12
- Foil Devices: 3 Longitudinal, 2 Transversal
Technical data
| Printics reference | U48231125 |
|---|---|
| Format | 750 mm x 1050 mm |
| Type | FLAT BED DIE CUTTER |
| Manufacturer | YOCO |
| Model | JY 105 E/T |
| Year | 2007 |
| Continent | EUROPE |
Dismantling and shipment
Dismantling and Loading
Estimated quotation for dismantling and loading is not provided.
Request a quotation for dimantling and loading.
Transportation and Logistic
Containers estimation for this machine is not provided.
